Bifascicular and trifascicular block


Bifascicular and trifascicular blocks keeps coming up in the college exams, for instance Question 15.1 from the second paper of 2017. It is a situation where both the right bundle branch AND one of the left bundle branch fascicles is not conducting. To make it trifascicular, one also needs to have a prolonged PR interval.

Here's a block from the author's own collection.

trifascicular block


Bifascicular block - RBBB and LPFB

The ventricles depolarize from the single remaining fascicle.
- This is a sign of extensive conducting system disease
- The example above is RBBB + LAFB:
Small Q waves and tall R waves in Lead I and aVL
Small R waves and deep S waves in Lead II, Lead III and aVF

But wait! … Isnt Left Bundle Branch Block (LBBB) a bi-fascicular block? Both the anterior and posterior fascicles are blocked!

Yes. Yes it is. In fact the guidelines from the European Society of cardiology include LBBB in their guidelines for management of bifascicular block.

"Trifascicular" Block

Its Bifascicular Block – with the important addition of a 3rd degree heart block. The common use of a prolonged PR interval (1st degree AV block) is no longer a supported reason to call something "trifascicular block", and in fact the AHA/ACCF/HRS have listed this term among their list of Forbidden Words which are "not recommended because of the great variation in anatomy and pathology producing such patterns."

How does this endanger my patient?

It may progress to complete heart block, and kill them ( 1% per year progress this way).

Management options

- If this ECG presents with a history of syncope, most would argue in favour of a pacemaker.
- In fact, if there is no reversible cause, a pacemaker is ideal.
- If a pacemaker is needed, make it a dual chamber

Looking for fascicular block whenever you see right bundle branch block

Whenever one sees RBBB, one may wish to look for additional fascicular block.

RBBB should not have any axis changes.

If there is RBBB with a right axis deviation, the posterior fascicle may be blocked as well.

(Lead III will have tall R waves)

If there is RBBB with a left axis deviation, the anterior fascicle may be blocked as well.

(Lead III will have deep S waves)



From "the ECG made easy", by Hampton (2003), and ECGs shamelessly stolen from Life in The Fastlane without any sort of permission, but in the non-commercial spirit of free education

2012 ACCF/AHA/HRS Focused Update of the 2008 Guidelines for Device-Based Therapy of Cardiac Rhythm Abnormalities A Report of the American College of Cardiology Foundation/American Heart Association Task Force on Practice Guidelines
